EXPORT GUIDE FOR FILLING MACHINES: MARKETS, HS, ORIGIN AND TRANSPORT

Mục lục nội dung ẩn
1 EXPORT GUIDE FOR FILLING MACHINES
EXPORT PROCEDURE · PACKAGING MACHINERY

EXPORT GUIDE FOR FILLING MACHINES

“Filling machine” may refer to a semi-automatic piston/servo filler, liquid or paste dosing filler, bottle/tube/jar filler, aseptic filler, or an integrated filler–capper–labeller. If the exporter does not freeze the principal function, container type, filled product, automation level, product-contact parts and line boundary, the shipment may be classified under the wrong HS code, supported by the wrong origin file, or packed and certified for the wrong scope.

This guide follows the shipment from market scan to post-shipment, with deeper review of Japan, China and the United States. Burkina Faso is noted as a high-value 2024 destination in importer-side data, but it is treated as a possible project-driven signal rather than the default target market.

1. QUICK OVERVIEW

MARKETS

WITS/UN Comtrade 2024 importer-side data for HS6 842230 shows notable imports from Vietnam by Burkina Faso, Japan, China, the United States and Pakistan. JP/CN/US are analyzed in depth because both trade evidence and compliance sources are clearer.

VIETNAM EXPORT POLICY

Ordinary industrial fillers require model-based screening; the product name alone does not create an export permit. Used status, dual-use features, batteries, residual liquids or explosion-protected components must be screened separately.

HS WORKING CODE

8422.30.00 is the main working direction where the principal function is filling/closing/sealing/labelling containers. Wrapping-only machines, parts and standalone dosing/weighing/pumping equipment need separate classification.

ORIGIN / FTA

China: ACFTA/RCEP. Japan: VJEPA/AJCEP/CPTPP/RCEP, although 8422.30 is currently Free in Japan’s 2026 tariff. The United States has no preferential FTA with Vietnam.

MARKET COMPLIANCE

There is no single certificate for every filler. Electrical safety, food-contact/GMP, hazardous location, pressure/pneumatic systems, wireless and exact end-use are the main triggers.

OPERATIONS

Control Production Freeze → Cargo Ready → SI/VGM/CY/CFS Cut-off → ETD. Rotary and aseptic lines need packed dimensions, GW/NW, CoG, lifting points, module mapping and residual-fluid/DG screening.

GLOSSARY: Market Access = conditions for entry/use in the destination market; PSR = product-specific rule of origin; Origin Audit Trail = evidence linking supplier/BOM to finished machine and proof of origin; CoG = center of gravity; FAT/SAT = factory/site acceptance tests.

2. PRODUCT SCOPE & TECHNICAL VARIANTS

This guide covers machines or integrated units whose principal function is placing product into bottles, cans, jars, tubes, bags or similar containers. It does not automatically cover every dosing device, pump, wrapper or scale marketed as a “filling system”.

VARIANT TECHNICAL SIGNS EVIDENCE HS / POLICY DIRECTION SEPARATE WHEN
Semi-auto liquid/paste filler Piston/gear/peristaltic, 1–4 nozzles Catalogue, cycle video, pump/nozzle specs Review 8422.30.00 where container filling is principal Do not treat a standalone dosing pump as the same product
Automatic linear/rotary filler Conveyor, starwheel, servo/PLC, multi-head Layout, I/O, throughput, electrical drawing 8422.30.00 is commonly the working direction Freeze machine boundary and accessories
Filler–capper–labeller monoblock Multiple packaging operations in one line Process flow, line layout, module list Classify by function/principal function and unit rules Do not split modules mechanically without a basis
Aseptic / sterile filler CIP/SIP, sterile barrier, HEPA/isolator, 316L contact parts P&ID, validation and material documents HS may remain 8422.30 but market compliance becomes much deeper Food/pharma GMP and sterile boundary
Form-fill-seal Forms the container, then fills and seals Process diagram, forming module description Review 8422.30 by exact function Do not confuse with wrapping-only 8422.40
Parts / nozzle / pump / control cabinet Shipped separately and incomplete Part no., BOM, exploded view Review parts heading or the component’s own heading Do not use complete-machine code for every spare part
Used/refurbished Year, serial, operating history Condition report and photos HS does not change merely because goods are used Destination-market used machinery rules
CLASSIFICATION CONTROL: if the equipment only meters by weight, only transfers liquid, or only wraps/overpacks, re-open classification. The catalogue must explain what the machine physically does to the container.

3. EXPORT MARKETS & MARKET ACCESS

WITS/UN Comtrade 2024 importer-side data for HS6 842230 reports imports from Vietnam of approximately USD 2.754 million by Burkina Faso, USD 1.739 million by Japan, USD 765 thousand by China, USD 471 thousand by the United States and USD 399 thousand by Pakistan. The HS6 bucket also includes closing, sealing, labelling and beverage-aerating machinery, so the figures are market signals rather than filler-only sales.

MARKET 2024 SIGNAL FIT ACCESS POINTS DATA TO FREEZE
Japan ~USD 1.739m from Vietnam High 8422.30 tariff Free; PSE only where in scope; food-contact apparatus may trigger Food Sanitation Act End-use, contact materials, importer handling, electrical scope
China ~USD 765k High CCC scope screening; whole filler should not be presumed CCC; ACFTA/RCEP origin can matter Model, electrical/Ex BOM, end-use, PSR
United States ~USD 471k Medium-high No single federal machine-import certificate; NRTL/workplace electrical and sanitary design may drive acceptance Electrical package, NRTL/field evaluation path, application, buyer spec
Burkina Faso ~USD 2.754m Project-driven High annual value but insufficient quantity/time-series evidence for a default target market Buyer/project, local approvals, service capability

Source: WITS/UN Comtrade 2024, importer-side, HS 842230 (HS 1988/92 H0). Do not combine with exporter-side figures to infer market share.

4. VIETNAM EXPORT POLICY

5. HS CODE – EXPORT DUTY – EXPORT VAT

5.1. HS working matrix

From 15 September 2026, customs classification and analysis for classification are governed by Circular 85/2026/TT-BTC, replacing Circulars 14/2015/TT-BTC and 17/2021/TT-BTC. Therefore, 8422.30.00 remains a working code until the actual technical file is locked.

SCOPE HS WORKING CODE WHY EVIDENCE MISCLASSIFICATION RISK
Complete filling/closing/sealing/labelling machine 8422.30.00 Heading text expressly covers the relevant packaging functions Catalogue, process video, container/product description Pump/doser/wrapper confusion
Other packing/wrapping machine 8422.40.00 Where principal function is other packing/wrapping Functional description Using 8422.30 just because equipment is in the same line
Packaging machinery parts Review 8422.90 or component heading Separate part may not retain complete-machine identity Part no., BOM, exploded view Complete-machine code for spares
Standalone dosing/weighing/pumping Review function-specific heading Principal function may fall outside 84.22 Principle and load-cell/pump data Marketing term “filling” used as classification

6. ORIGIN / FTA / C/O

Filling machines often contain imported PLC/HMI, servo motors, pumps, valves, load cells, sensors, stainless fabrication, conveyors and control panels. Origin therefore must be BOM-first, not a certificate exercise after packing.

ROUTE FTA / PROOF RULE TO CHECK PRACTICAL VALUE BASE FILE
Vietnam → China ACFTA Form E / appropriate RCEP proof ACFTA HS 8422.30: RVC40 or CTSH. Under RCEP, HS 8422.30 also follows CTSH or RVC40; verify the applicable HS version and agreement file. May provide preference only when all importer and origin conditions are met BOM, component HS/origin/value, supplier and production records
Vietnam → Japan VJEPA/AJCEP/CPTPP/RCEP where relevant Compare PSR and buyer needs Japan 2026 tariff shows 8422.30 as Free; preferential proof may add no tariff benefit when final HS matches Only produce preferential proof with a clear objective
Vietnam → United States No preferential US-Vietnam FTA Non-preferential origin/marking and buyer documents Do not promise a preferential C/O to reduce duty BOM/origin and commercial records
CHANGE CONTROL: changing PLC, motor, pump, valve, stainless skid, control cabinet or supplier after Production Freeze can change RVC or tariff-shift results. Re-run origin review before issuing proof.

7. PRODUCT-SPECIFIC & MARKET COMPLIANCE

Compliance depends strongly on the filled product and end-use: food/beverage, pharmaceutical, cosmetics, chemicals or flammable liquids. Separate destination law from buyer specification and from transport triggers.

JP

JAPAN

8422.30: FREE 2026FOOD-CONTACT TRIGGER
CONCLUSION

Do not assume every electrically powered filler requires PSE. PSE applies only where the machine or supplied electrical item falls within DENAN scope.

KEY REQUIREMENTS
  • MHLW can treat machines that directly contact food/additives as “apparatus”.
  • Food Sanitation Act Article 27 can require importer notification for apparatus imported for sale or business use.
  • Contact-material/test evidence may be requested during quarantine review.
FREEZE BEFORE SHIPMENT
  • Food vs non-food end-use
  • 316L/gasket/hose contact-material list
  • Importer confirmation on Article 27
  • PSE scope of separately supplied items
CN

CHINA

CCC SCOPE SCREENINGACFTA / RCEP
CONCLUSION

Do not assume that an entire filling machine requires CCC merely because it contains a motor or PLC. Check the current CCC catalogue and implementation rules against the exact machine/components; explosion-proof electrical equipment is a separate trigger for hazardous-area applications.

KEY REQUIREMENTS
  • Screen electrical/components that are independently in CCC scope.
  • Explosion-proof electrical equipment is a separate CCC category and matters for hazardous-area fillers.
  • Confirm national/local standards, manuals and site acceptance with the importer.
FREEZE BEFORE SHIPMENT
  • Electrical BOM + Ex rating
  • Whole machine vs separately supplied component
  • Chinese manual/label inputs
  • Form E/RCEP route and origin evidence
US

UNITED STATES

NO SINGLE FEDERAL MACHINE CERTNRTL / GMP TRIGGERS
CONCLUSION

OSHA does not certify machinery generally. Nevertheless, certain workplace electrical equipment must be approved/accepted under the NRTL framework, and buyers/AHJs may require listing or field evaluation.

KEY REQUIREMENTS
  • Screen industrial control panels/electrical systems against relevant NRTL standards.
  • For food use, 21 CFR 117.40 addresses cleanability, maintenance and contamination prevention.
  • Pharma/supplement buyer GMP qualification can be materially deeper.
FREEZE BEFORE SHIPMENT
  • Site/AHJ and NRTL route
  • Control-panel evidence if required
  • Product-contact materials and cleanability
  • FAT/SAT, manuals, wiring and spares

COMMON LOGISTICS TRIGGERS

TRIGGER DATA REQUIRED OPERATIONAL EFFECT
Residual oil / cleaning liquid Substance, SDS, quantity, drain status Leak prevention, DG screening, carrier acceptance
Battery/UPS Chemistry, Wh, UN38.3/SDS if applicable Air/sea DG booking
Wood packaging Solid wood vs plywood; treatment mark ISPM 15 by route/market
Heavy/OOG Packed L×W×H, GW, CoG, floor load, lifting points Container fit, FR/OT/OOG, crane/forklift
Hazardous-area design Ex component list, certificates, zone rating Market and site acceptance

8. EXPORT DOCUMENT SET & SUBMISSION

GROUP DOCUMENTS USED FOR OWNER DATA TO MATCH COMMON FAILURE
Commercial Contract/PO, Invoice, Packing List Customs, booking, buyer/bank Sales/Docs Model, qty, price, Incoterm, scope Generic “machine” description; PO scope mismatch
Customs Declaration + classification evidence Export clearance Customs/Docs HS, description, value, origin No explanation of 8422.30 vs 8422.40/parts
Technical/compliance Catalogue, layout, electrical, P&ID, manuals, test/certs Market/buyer acceptance Engineering/QA Exact model, serial, voltage, contact material Certificate scope mismatch
Origin BOM, supplier docs, C/O input, RVC/CTSH evidence Origin review/C/O Procurement/Factory/Docs Finished/input HS, supplier, value, batch Prototype BOM used instead of shipped BOM
Transport/buyer Booking, SI, VGM, B/L/AWB, FAT/SAT, L/C docs Shipping/post-shipment Forwarder/Docs/Finance Packages, GW/NW, marks, consignee, serial SI/B/L mismatch; missing crate map
ONE SOURCE OF TRUTH: freeze commercial description, technical description, HS working code, model/serial, quantity, packages, GW/NW, packed dimensions, origin, marks, Incoterm, buyer PO and consignee in one master dataset.

9. LEGAL MATRIX – THREE LAYERS

LAYER LEGAL SOURCE AUTHORITY EFFECTIVE / TIMING SCOPE CHANGE / NOTE
Vietnam – Foreign trade Decree 292/2026/ND-CP Government 05 Sep 2026 Prohibitions/restrictions/licensing framework Replaced Decree 69/2018; apply only relevant triggers
Vietnam – Customs Decree 08/2015 + 59/2018 + 167/2025; Circular 38/2015 + 39/2018 + 121/2025 Government / MOF Decree167: 15 Aug 2025; Circular121: 01 Feb 2026 Declaration, dossier, inspection Use current amended text
Vietnam – Export tariff Decree26/2023 + Decree201/2026 Government Decree201: 23 Jul 2026 Export Tariff Check final HS; do not infer from import MFN
Vietnam – VAT Law48/2024; Decree181/2025; Decree359/2025; Decree144/2026 National Assembly / Government Decree144: 20 Jun 2026 Export VAT / 0% conditions Check actual transaction and evidence
Origin Circular40/2025 + decentralization changes under Circular26/2026 MOIT Circular40: 01 Jul 2025; authority changes from 01 Aug 2026 C/O issuance/self-certification authority Check correct issuing body at filing date
ACFTA Circular12/2019/TT-BCT MOIT 12 Sep 2019 Form E / ACFTA PSR 8422.30 cited PSR: RVC40 or CTSH
Japan 2026 tariff; Food Sanitation Act Art.27; DENAN/PSE guidance Customs / MHLW / METI Current 2026 Tariff, food-contact apparatus, electrical scope No blanket PSE rule
China CCC catalogue / current implementation rules SAMR/CNCA Current 2026 Compulsory certification by listed scope Whole filler is not automatically a CCC product
United States OSHA NRTL framework; 21 CFR 117.40 when food-use applies OSHA / FDA Current Workplace electrical acceptance / food equipment sanitation Not a blanket customs certificate

10. PRACTICAL E2E EXPORT PROCESS

01
PRE-CONTRACT

Freeze product scope and market

Define filled product, container, capacity, filling principle, line scope, sanitary/hazardous-area requirements and buyer acceptance path.

LOCK

Exact model, application, market route.

GATE

Do not quote a standard filler for aseptic/Ex/GMP use.

02
CLASSIFICATION

HS, policy and origin route

Separate 8422.30 complete fillers from wrapping-only equipment, parts and standalone dosing/weighing/pumping. Screen Vietnam policy and destination triggers.

LOCK

HS working/final code + origin strategy.

GATE

The label “filling system” is not sufficient classification evidence.

03
COMMERCIAL SETUP

Contract and compliance deliverables

Freeze Incoterm, payment, FAT/SAT, warranty, spares, manuals and responsibility for NRTL/PSE/food-contact/CCC screening and commissioning.

LOCK

PO/Contract + master data.

GATE

Do not leave tests/certificates undefined until shipment.

04
BEFORE CARGO READY

Production Freeze and dossier

Freeze BOM, contact parts, electrical options, safety guards and accessories. Complete FAT, manuals, market documents, origin calculation and packaging engineering.

LOCK

BOM revision, FAT release, compliance/origin evidence.

GATE

Component changes after freeze require origin and buyer re-check.

05
BOOKING

Packing, modules and transport

Freeze packed dimensions, GW/NW, CoG, lifting/forklift points, residual liquids, batteries, wood packaging, container fit and OOG status.

LOCK

Booking data + packing plan.

GATE

Do not book using machine overall dimensions when disassembled.

06
EXPORT CUSTOMS

Declaration and cross-check

Cross-check Invoice, PL, catalogue, HS, origin, model/serial and line scope before declaration. Keep crate/module mapping for split-container shipments.

LOCK

HS, description, value, packages, origin.

GATE

All documents must describe the same machine/line.

07
CUT-OFF CONTROL

SI, VGM, CY/CFS and B/L draft

Freeze shipper/consignee, marks, packages, weights, container, SI/VGM and on-board data. Draft B/L must align with Invoice/PL/C/O and bank requirements.

LOCK

Carrier data + milestone control.

GATE

Late SI/VGM or package errors create amendments and discrepancies.

08
POST-SHIPMENT

Final documents and commissioning archive

Complete Final B/L/AWB, proof of origin if used, buyer/bank set, payment, FAT/SAT handover, commissioning records and claims if any.

LOCK

Final dossier + payment + audit trail.

GATE

Archive must reconstruct the shipped BOM/configuration months later.

11. TIMELINE BEFORE ETD / CARGO READY / CUT-OFF

MILESTONE FREEZE DATA OWNER RISK IF LATE
Before Contract Market access, HS direction, Incoterm, payment, compliance scope Application, buyer spec Sales/Engineering/Compliance Order accepted before configuration can pass market/site
Before Production Freeze BOM, contact parts, electrical/Ex, manual/label inputs, origin version BOM rev., drawings, supplier evidence Engineering/Procurement/QA Component change breaks origin or approval
Before Cargo Ready FAT, docs, packing, booking FAT, manuals, packed dims, GW/NW, CoG Factory/QA/Docs Machine complete but shipment not ready
Before CY/CFS cut-off Customs, trucking, stuffing/gate-in Declaration, booking, crate map Ops/Customs/Forwarder Roll/rebooking/storage
Before SI/VGM cut-off Carrier data, package count/weights, B/L draft SI, VGM, shipper/consignee/marks Docs/Forwarder Amendment/discrepancy
After on-board Origin proof, Final B/L, bank/buyer set, payment On-board and origin/bank data Docs/Finance Late clearance/payment

12. INCOTERMS – TRANSPORT – PACKING – COST

Small fillers may move by LCL or air; rotary monoblocks and multi-module lines usually favour FCL. Oversized skids/guards/conveyors may require Open Top, Flat Rack or OOG handling. Select the mode based on damage risk, module size, lifting, commissioning sequence and deadline, not freight alone.

  • ✓ Packed L×W×H per crate/module
  • ✓ GW/NW + CoG
  • ✓ Lifting/forklift points
  • ✓ Floor load / skid base
  • ✓ Nozzle/starwheel/load-cell/HMI protection
  • ✓ Clean, dry and capped contact surfaces
  • ✓ Residual liquids declared/drained
  • ✓ Battery/UPS DG screening
  • ✓ ISPM 15 where relevant
  • ✓ Crate map by installation sequence
  • ✓ Moisture/corrosion protection
  • ✓ Stuffing/lashing photos
INCOTERMS: FCA/FOB/CIF/CIP/DAP/DDP may all appear. Contract scope must separately state unloading, rigging, installation, utilities, FAT/SAT, commissioning and site acceptance. Risk transfer and cost transfer are not always the same point.

13. RISKS & CONTROL POINTS

RISK ROOT CAUSE IMPACT CONTROL TIMING
Wrong 8422.30 vs pump/packing/parts Classification by trade name Customs/C/O correction Technical classification sheet Pre-contract
Japan Food Sanitation trigger missed No food-contact scope check Import notification/test delay Contact-material list + importer confirmation Pre-contract/Freeze
Japan C/O with no tariff benefit Assuming FTA always saves duty Unnecessary lead time Check final Japan tariff Origin review
Blanket CCC assumption in China “Electrical machine = CCC” Wrong testing/certification cost CCC scope screen Pre-contract
Ex component missed in China No hazardous-area BOM Component hold/replacement Ex list + scope Production Freeze
US site rejects electrical package No NRTL/AHJ route Field rework/commissioning delay Buyer/AHJ/NRTL path in Contract Pre-contract
Food/pharma cleanability failure Wrong MOC/gasket/weld design FAT/SAT rejection URS + MOC + weld/passivation records Design/Freeze
Origin fails after BOM change Calculation uses old BOM Preference loss/verification BOM change control Before proof
Residual fluid/DG issue Oil/chemical not declared or drained Carrier rejection/claim SDS + drain checklist Before booking
Crate does not fit Overall machine size used Repacking/OOG/rebooking Container-fit review Before booking
CoG/lifting error Not recalculated after disassembly Damage/safety incident Lift plan + marked CoG Packing/loading
B/L/C/O/serial mismatch Multiple data sources Amendment/L/C discrepancy/origin query One source of truth Before release

14. FAQ

1. Can standard filling machines be exported from Vietnam normally?

Usually yes where no specific control trigger applies, but exact model, end-use, components and destination rules must be screened before a final conclusion.

2. Does HS 8422.30.00 cover every “filling” machine?

No. It fits equipment whose principal function falls within filling/closing/sealing/labelling containers. Pumps, dosers, weighing systems and wrappers may classify elsewhere.

3. Must a filler–capper–labeller be split into separate machines?

Not automatically. Where exported as a functional unit, classify the unit according to the applicable functional-unit/principal-function logic and evidence.

4. What is different for food fillers imported into Japan?

Food-contact machine parts can fall under the Food Sanitation Act definition of apparatus, and importers may need Article 27 notification. Freeze contact materials and supporting test evidence.

5. Does every electrically powered filler need PSE in Japan?

No. Screen exact electrical products/components against DENAN scope; the Japanese importer bears obligations only where the goods are in scope.

6. Is preferential C/O always necessary for Japan?

No. Japan’s 2026 tariff shows 8422.30 as Free, so preferential proof may not create extra duty savings when final HS matches.

7. Does a filling machine for China automatically need CCC?

No blanket conclusion. The current CCC catalogue does not list filling machines as a standalone category; screen components and explosion-proof products by exact scope.

8. What ACFTA origin rule applies to 8422.30?

The currently cited ACFTA PSR is RVC40 or CTSH. Verify HS version, PSR and actual BOM before issuing Form E.

9. Does a filler exported to the US always need UL/NRTL certification?

There is no single federal customs certificate for every filler. Workplace electrical equipment may need NRTL approval/acceptance, and the buyer/AHJ may require listing or field evaluation.

10. Does FDA certify food filling machines?

FDA requirements such as 21 CFR 117.40 govern equipment used in food facilities for cleanability and contamination control; this should not be described as FDA certification of every imported machine.

11. When is the machine Cargo Ready?

Only when both physical goods and shipment data/compliance are ready: FAT released, BOM frozen, packed dimensions/GW/NW/CoG known, crate map complete and required market documents available.

12. What must be archived after sailing?

Customs, final transport documents, origin file, shipped BOM, market compliance evidence, technical/manual drawings, packing/lifting proof, bank/payment and commissioning/warranty records.

15. FINAL OUTPUTS & POST-SHIPMENT ARCHIVE

The archive should allow another employee to reconstruct which machine and serial shipped, filling principle, BOM revision, market-compliance route, origin basis, crate/module structure and buyer document set months later.

  • ✓ Export customs file
  • ✓ Contract/PO + final Invoice/PL
  • ✓ Final B/L/AWB/Sea Waybill
  • ✓ C/O/proof + Origin Audit Trail
  • ✓ Catalogue, layout, electrical/P&ID
  • ✓ FAT/SAT/commissioning/warranty
  • ✓ Market/importer confirmations
  • ✓ Packing/lifting/lashing evidence
  • ✓ Buyer/bank docs + payment
  • ✓ Claim/survey records if any

RECOMMENDED OPERATING APPROACH

For filling machinery, the key checkpoints are Production Freeze and Cargo Ready. Freeze BOM/contact parts/electrical scope before origin and market-compliance closure; issue booking only after packed dimensions, weights, CoG, residual-fluid/battery screening and crate mapping are confirmed.

Compliance & Origin

Review HS, Vietnam policy, Japan food-contact/PSE, China CCC scope, US NRTL/GMP, ACFTA/RCEP and the exact-model Origin Audit Trail.

Shipment Control

Synchronize Invoice–PL–customs–SI–VGM–B/L–origin proof; control packing/lifting/OOG and buyer/bank/commissioning documents through post-shipment.

QUICK CONSULTATION

NEED TO REVIEW IMPORT PROCEDURES OR A SHIPPING PLAN?

Send us the product name, shipping route, current dossier, or implementation request in advance so we can suggest a suitable approach that is practical, focused, and aligned with your shipment.

CALL NOW
Zalo
HOTLINE 0963 856 664 / 0982 135 393
EMAIL info@tgimex.com
SUITABLE FOR International shipping · Customs procedures · Import licenses · B2B logistics

Leave a Reply

Discover more from TGIMEX VIETNAM JSC

Subscribe now to keep reading and get access to the full archive.

Continue reading
